SWAC05,Digital SPDIF Audio Switch 3x1 With IR remote control

FEATURES

1.Support 3 S/PDIF inputs, and 1 S/PDIF output, User can select any of 3 digital audio to display on one Audio receivers.

2.Audio format support : LPCM2.0/DTS/Dolby-AC3

3.Support signal retiming

4.Use the line loss less than 0.2dB.M optical cable ,transmit distance can reach up to 40M.

5.Support last time working state memory when power off

6.Support over-voltage protection can prevent the damage caused by connecting the LED status indication

7.LED status indication

8.Support IR remote and manual control.

9.Support lossless transmission.

10.Compact design, easy to install.

11.USB 5V power supply.

SPECIFICATIONS:

Support audio format………………………………………………………..LPCM2.0/DTS/Dolby-AC3

Peak wavelength………………........................................... ……...............................………650nm

Max baud rate…..…………….………...…………………………………………………………16Mbps

Output cable distance .. …………………≤40m(Use the optical fiber cable loss less the 0.2Db/m )

Max working current………………………………………………………………..……………...100mA

Power adapter format……………………....…. …....…. …....…. …....…. …....…. …....…. USB5V

Operating Temperature range……..…………….……...………………………………… (0 to +40℃)

Operating Humidity range…………….…………. …….……….….5 to 90%RH (No Condensation)

Dimension (L x W x H)……………………………………….…….……….…………62x58x24 (mm)

Weight…..……………………………………………………………..……..………………………72g
