SWSP07A,HDMI 2.0 Splitter 1 in 2 out support HDCP 2.2 with Scaler

Features：

1. Supports resolutions up to UItra HD 4Kx2K(3840x2160@60Hz YUV 4:4:4 ).

2. Supports HDCP2.2/1.4 Compliant.

3. Supports 36 bit Deep Color.

4. Supports LPCM 7.1, Dolby  TrueHD, Dolby digital  Plus, and DTS-HD  Master Audio.

5. Support 3D.

6. Bandwidth 18G.

7. Support HDR.

8.Power supply is optional.

Specification:

HDMI version......................................HDMI 2.0

HDMI resolution..................................up to 3840x2160P/60Hz YUV444

Support video color format................30/36/48 bit deep color

Support audio format..........................DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD HD(HBR)

Max bandwidth.....................................1536MHz

Max baud rate.......................................18Gbps

Input cable distance.................................≤8m AWG26 HDMI standard cable

Output cable distance..............................≤8m AWG26 HDMI standard cable

Max working current..............................1200mA

Operate Frequency...................................up to 600mhz

Input DDC signal..........................................5 Volts P-P(TTL)

Input video signal .......................................0.5-1.0 volts p-p
