SWSP07C, HDMI 2.0 1X2 HDMI Splitter & 2x1 HDMI Switch with metal case

FEATURES

1.Cascaded: Large distribution achieved by cascading the HDMI Amplifier Splitter

2.2 HDMI-Host (DVD Player or PS3) to 1 HDMI Monitor or TV

3.1 HDMI-Host (DVD Player or PS3) to 2 HDMI Monitor or TV

4.MAX operation current:15ma

5.Full compliance with the HDMI Specification V1.0,V1.1,V1.2,V1.3,V1.4.V2.0

6.Main control: Manual electron select

7.With 2 LED & display working port

LED : 2 (Blue),Display working port

8.Easy install & operation

9.Support HDMI Plug & Play

10.Support input up to 5metres AWG26 HDMI standard cable length,output up to 5metres AWG26 cable length

11.Support 3D,4K@60hz YUV444,HDCP 2.2

Specification:

Input DDC Signal........................................................5 volts p-p (TTL)

Maximum Single Link Range........................................................4kx2k@60hz YUV444

Output Vide........................................................V1.0, V1.1, V1.2, V1.3, V1.4.V2.0

Vertical Frequency Range........................................................50/60Hz

Video Amplifier Bandwidth........................................................340MHz/3.4Gbps

Progressive(50&60Hz)........................................................480p,576p,720p,1080p,4Kx2K@60hz

Operating Temperature........................................................0 ℃ to +70℃

Operating Humidity........................................................10% to 85 % RH (no condensation)

Storage Temperature........................................................-10℃ to +80℃

Storage Humidity........................................................5% to 90 % RH (no condensation)

External Power Supply........................................................No power needed

Power consumption (Max)........................................................5W
