SWMX22,HDMI Matrix 2x2

Features:

1. Support HDMI 2.0/HDCP 1.4

2. Support 3D video format

3. Support highest resolution up to 4K@60Hz, YUV 4:2:0

4. Support deep color 8/10/12 bit

5. 2 HDMI inputs switch and split to 2 HDMI displays

6. Extra power is needed.(DC5V/1A)

Specifications:

HDMI version...........................................................HDMI1.4B

HDMI resolution...........................................................up to 3840x2160P/60Hz YUV4：2：0

Support Video format...........................................................8/10/12 bits deep color

Support Audio format...........................................................DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max bandwidth...........................................................340MHz

Max baud rate...........................................................10.2Gbps

Input cable distance...........................................................10m AWG26 HDMI1.4 standard cable

Output cable distance...........................................................15m AWG26 HDMI1.4 standard cable

Max working current...........................................................600mA

Power adapter format...........................................................Input: AC (50Hz, 60Hz) 100V-240V; Output:DC 5V/2A

Dimensions(L*W*H)...........................................................170X56X24mm

Weight...........................................................380g
